DESCRIPTION
TIP SPECIFICATIONS CANTILEVER SPECIFICATIONS High aspect ratio probe for small scale structures. This model offers 100nm tall cylindrical shaped pillar tips with 40nm base diameter, combined with an intermediate 2.8N/m spring constant. As with all Adama probes, these are formed out of single crystal boron doped diamond and are wear resistant and conductive. Suitable for electrical characterization with PeakForce TUNA, TUNA, and CAFM Tip Geometry:
Standard Tip Height:
12.5 +/- 2.5 Front Angle:
25+/-5 Back Angle:
15+/-5 Side Angle:
22.5+/-5 Tip Radius (Nom):
40 Tip Coating:
Highly conductive single cystal diamond Tip Set Back (Nom):
15-25 Tilt Compensation:
5 +/- 1 Cantilever Material:
Diamond pillar, 40nm-w, med-k, 5pk Cantilever Thickness (Nom):
1.5 Cantilever Thickness (RNG):
1 – 2 Cantilever Geometry:
Rectangular Cantilevers Number:
11 – 31 Back Side Coating:
Reflective Au
